Air Mix Damper Control Servo Motor Circuit (Passenger Side) (B1441/41)
DESCRIPTION
The damper servo sub-assembly (front passenger side air mix damper servo) sends
pulse signals to inform the No. 1 air conditioning amplifier assembly of the damper
position. The No. 1 air conditioning amplifier assembly activates the motor (no ...
