COMPONENTS
ILLUSTRATION
Inspection
INSPECTION
PROCEDURE
1. INSPECT MAGNET CLUTCH ASSEMBLY
(a) Check the magnet clutch operation.
(1) Confirm that the magnet clutch hub and magnet clutch rotor lock when the
positive (+) lead of the battery is connected to terminal 3 of the magnet clutch, ...
Ambient Temperature Sensor Circuit (B1412/12)
DESCRIPTION
The cooler thermistor (ambient temperature sensor) is installed in the front
part of the cooler condenser assembly to detect the ambient temperature and control
the air conditioning auto mode. The sensor connected to the air conditioning ampli ...
